6 mm/ .243 family Recipe book

yan014

Member
Rating - 100%
166   0   0
Location
Quebec
Good day ladies and gentleman,

Let's start a Recipe book for everyone to post their winning recipes in 6mm / .243 family

First and foremost, there are a few things that need to happen here for this post to be successful.

1: We need to stick to a pre-established format.
2: We only post recipes. No congratulations, questions or any other posts than recipes.
3: Questions or congrats to posters about certain recipes to be directed via PM so it doesn't clutter the original post with things other than recipes.

One very important thing, a recipe that works in a firearm may not work in yours. When the recipe is HOT (close or above recommended amount of powder), work your way up to it. . This is serious stuff. It can cause catastrophic failure of your firearm or hurt you or someone. We are mostly all grown ups, let's use our heads if the recipe is hot. WORK UP TO IT.

Here's a format that seems to make sens.

Caliber:
Rifle brand:
Rifle Model:
Custom built:
Barrel length and twist:
Projectile brand, model and weight:
Powder brand and weight:
LOAD CONSIDERED HOT OR CLOSE TO MAX:
Primers:
Coal:
Ogive length:
Brass:
Brass length:
Distance to lands:

Results at 100, 200, 300 (whatever is available)

If available:
Velocity (average):
Outside temperature:
Wind and direction:
Barometric pressure and other relevant data:

Thank you very much everyone and let's make this a successful post for everyone that are getting into reloading a new caliber or are lost in the amount of options available in this caliber. This will also be awesome for anyone who's looking for a start point or simply improve their own recipe or try something else. It will also tremendously simplify the search and the amount of time spent on the search button option and the read through the hundreds of posts and irrelevant reading someone will have to go through in order to get a start point!

We all know that something that does wonders in someone's rifle may not work in someone else's rifle even if it is the exact same thing only a few different serial number away.

Once again, thank you everyone for your participation in this recipe and let's make it a go to for anyone who needs it.

Last edited:
THESE ARE ALL 6X45 ALL IN THE SAME RIFLE.


Caliber: 6x45
Rifle brand: Custom
Rifle Model: Used to be a Savage model 11
Custom built: Yes
Barrel length and twist: 26" 8 twist
Projectile brand, model and weight: Berger 105gr vld target
Powder brand and weight: Imr 8208xbr
LOAD CONSIDERED HOT OR CLOSE TO MAX: No
Primers: Cci Small Rifle
Coal: 1.993" to ogive
Ogive length:
Brass: Hornady
Brass length: 1.750"
Distance to lands: .020"

Velocity: 2611fps.

100 yards 5 shots .342"





Projectile brand, model and weight: 58gr hornady vmax
Powder brand and weight: H335 28gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: Probably
Primers:CCi Small rifle
Coal:1.924" at ogive
Brass: RP
Brass length: 1.750
Distance to lands: A lot

Velocity is 3295fps.



Projectile brand, model and weight: 70gr Smk
Powder brand and weight: H4895 26.5gr
LOAD CONSIDERED HOT OR CLOSE TO MAX:Yes
Primers: CCI Small Rifle
Coal: 2.005
Brass: RP
Brass length: 1.750
Distance to lands: Unsure

Velocity: 3017fps


Projectile brand, model and weight: 55gr Nosler varmageddon
Powder brand and weight: 27gr h4895
LOAD CONSIDERED HOT OR CLOSE TO MAX:
Primers: CCI small rifle
Coal: 1.887 to ogive
Brass: RP
Brass length: 1.750"
Distance to lands: A lot

Velocity: 3190fps



Projectile brand, model and weight: Speer 85gr btsp
Powder brand and weight: Imr8208xbr
LOAD CONSIDERED HOT OR CLOSE TO MAX: At hodgdon listed max
Primers: CCI Small Rifle
Coal: 1.980" to ogive
Brass: RP
Brass length: 1.750"
Distance to lands: Lots

Velocity: 2975fps

I have more loads but that is a good start.

Caliber:243
Rifle brand:Ruger Weatherby Remington savage.
Rifle Model:
Custom built:no
Barrel length and twist:factory
Projectile brand, model and weight:95gr SST
Powder brand and weight:H 4831. 44.5gr
LOAD CONSIDERED HOT OR CLOSE TO MAX:safe
Primers:CCI br2
Coal:
Ogive length:
Brass:Winchester
Brass length:
Distance to lands:.005 off
shoots under a inch in all makes I have try. May have to back off a .5 or1.0 gr to maximize groups.

Last edited:
Caliber:243
Rifle brand: Savage
Rifle Model: 11
Custom built: no standard sported weight barrel but rifle basix trigger.
Barrel length and twist: 1 in 9.25
Projectile brand, model and weight: hornady 65gr v-max
Powder brand and weight: IMR 4350 44.4gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: no mid weight load.
Primers:CCI-200 large rifle
Coal: Sami spec from Lyman 49th
Ogive length: n/a
Brass: Winchester
Brass length: 2.035
Distance to lands: n/a

.5 moa @100yrds consistent @200 and 300 yrds

Caliber: .243 Winchester
Rifle brand: Savage
Rifle Model: Model 11 Lightweight hunter
Custom built: No
Barrel length and twist: 20" 1 in 9.25


Projectile brand, weight and model: Hornady 87gr. BTHP
Powder brand and weight: Imr 4320, 33.9gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: No
Primers: CCI Large Rifle
Brass: Winchester

Caliber: 243 win
Rifle brand: Tikka
Rifle Model: T3 Lite
Custom built: No
Barrel length and twist: 22.5" 1:10 Twist
Projectile brand, model and weight: Sierra 85 grain HPBT
Powder brand and weight: IMR 4350 44 grains
LOAD CONSIDERED HOT OR CLOSE TO MAX: Max Load
Primers: Win LG Rifle
Coal: 2.60"
Ogive length:
Brass: Federal
Brass length:
Distance to lands:
I had to shorten oal as book spec was to long for this chamber. This load grouped at 7/8" on a very windy day.

UPDATE: I tried this same load today with much less wind to worry about and I got a .622" group and an average velocity of 3280 fps.
Here is a link to a picture of a 5 shot group.
https://www.dropbox.com/s/uk2oqfaqkrpytkc/2435Shots.jpg?dl=0

Last edited:
Chambering: 6mm Remington 700 Remington platform
Custom By Bill Leeper
Benchmark HB C-M 1-8" twist, 26"
Thick recoil lug installed.
Jewell trigger at 4 oz.
Berger 105 VLD Target with 46.3 grains of H4831sc
Lapua 105 Scenar with 46.8 grains of Vihtavuori N165
Primer: CCI BR-2
Stock; Remington Varmint Laminate, bedded
Seating: VLD Jammed .005; Scenar .010 off lands at throat.
Either of these loads will shoot .3 moa or better if I do my part.
D.

Chambering: 6mm BR Norma on a Shilen DGA platform.
Robertson BR Stock [Bright Blue]
Pillar bedded and free floated Benchmark 1-8" twist SS Barrel 27"
Jewell trigger at 4 oz.
Lapua 6mmBR Brass, neck turned to fit the chamber.
BR-4 CCI primers. Load: 105 Lapua Scenar, chased by 30.3 grains of Varget.
COL at 2.24" [.005" off lands]
True ¼ moa rifle if I do my part. [shot a 1.28", 5-shot group at 500M]
D.

Caliber: 243 win
Rifle brand: Tikka
Rifle Model: T3 Lite
Custom built: No
Barrel length and twist: 22.5" 1:10 Twist
Projectile brand, model and weight: Hornady 87 grain HPBT
Powder brand and weight: Win760 42 grains
LOAD CONSIDERED HOT OR CLOSE TO MAX: .5 grains under Max Load
Primers: Win LG Rifle
Coal: 2.65"
Ogive length:
Brass: Federal
Brass length:
Distance to lands:
This load produced a 3/4 group on a very windy day.

Caliber: 243 win
Rifle brand: Tikka
Rifle Model: T3 Lite
Custom built: No
Barrel length and twist: 22.5" 1:10 Twist
Projectile brand, model and weight: Hornady 87 grain HPBT
Powder brand and weight: IMR 4350 45 grains
LOAD CONSIDERED HOT OR CLOSE TO MAX: Max Load could be hot
Primers: Win LG Rifle
Coal: 2.65"
Ogive length:
Brass: Federal
Brass length:
Distance to lands:

This load produced a .715" group with an average velocity of 3289 fps.

Caliber: 243 win
Rifle brand: Savage
Rifle Model: Model 10
Custom built: Yes, assembled from factory barrel, receivers, and stocks. aftermarket triggers
Barrel length and twist: 22" 1:9.25 Twist
Projectile brand, model and weight: Barnes 85 TSX and 90gr Nosler E-Tip
Powder brand and weight: H 4350 as below
LOAD CONSIDERED HOT OR CLOSE TO MAX: Near Max Loads, could be considered hot
Primers: CCI BR2
Coal: as below
Brass: Winchester
Brass length:2.035
Distance to lands: as below
Temp: 25 degrees C, very little wind.

Finalized some loads for 243 win using 85gr TSX and 90gr Nosler E-tip. Two different savage 10 rifles I cobbled together. 22" factory barrels 9.25 twist. H4350 with CCI BR2 lighting them up in Winchester cases.
Rifle 1: 85tsx 42.5gr H4350 outstanding sub moa groups @100m. 60 jump COAL 2.705. (load at 43.0 is starting to show pressure signs.) Should be an outstanding game getter.
Rifle 2: 90gr E-tip 41.5gr H4350 clover leaf cluster @100m. 30 jump COAL 2.700. (load at 42.0 is showing pressure signs) New to this load and bullet in the 243 and should be another great game getter.
Sorry no chrony data as if was acting up today.

Please notice these are well above published loads and my rifles practical max so as always...work up. However it appears those loads you read on the Hodgdon or Nosler site for these bullets are rather lawyered up for H4350 in my rifles.

Elkys 243s....

Last edited:
Caliber: 243 win
Rifle brand: Tikka
Rifle Model: T3 Lite
Custom built: No
Barrel length and twist: 22.5" 1:10 Twist
Projectile brand, model and weight: Hornady 75 VMAX
Powder brand and weight: IMR4350 44.5 grains
LOAD CONSIDERED HOT OR CLOSE TO MAX: Yes
Primers: Win LG Rifle
Coal: 2.62"
Ogive length:
Brass: Federal
Brass length: 2.037
Distance to lands: .010
This load produced a 3 shot 5/8" group and a 5 shot group measuring .682"

Last edited:
Caliber: .243
Rifle brand: NEF
Rifle Model: Handi-Rifle
Custom built: no
Barrel length and twist: 22 1:10
Projectile brand, model and weight: Hornady 95gr SST
Powder brand and weight: IMR 4831 41gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: Close. 42.5 Hornady's recommended max load. 1.5 gr under.
Primers: Winchester ? Bought them a while ago and threw away the box.
Coal: 2.778
Ogive length:
Brass: Hornady
Brass length: 2.045
Distance to lands: 0.002 off the lands.

Groups under an inch at 100, have yet to try further, need to get a better rest or bipod.



Attachments

  • IMG_17102017_214730.jpg
    55.8 KB · Views: 540
Last edited:
Caliber: 6mm Rem
Rifle brand: Remington
Rifle model: Six (pump)
Custom built: No
Barrel lenth and twist: 22" 1:9 twist I believe
Projectile brand, model, weight: Hornady SST 95gr
Powder brand and weight: IMR 4350 42gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: 43gr is max so hot ...
Primers: Remington LR primers
Brass: New Hornady
Coal:
Ogive:
Brass length:
Distance to lands:
Air temperature:5 degrees C

Results: leaning on a tailgate, leupold 1.25x4 grouped 1" and could have shot better on my part.

Caliber: .243
Rifle brand: Savage
Rifle model: Axis
Barrel length and twist:22" 1:9.25
Projectile brand, model, weight: Nosler Ballistic tip 95gr
Powder brand and weight: Hodgdon H4350 40gr.
LOAD CONSIDERED HOT OR CLOSE TO MAX: Yes
Primers. Win LR or Federal 210
Brass: Hornady
Brass length:2.035
COAL:2.65
Consistantly groups 4 shots under an inch at 100yds.

243 win 75 gr Vmax

Caliber:243 win
Rifle brand:Win
Rifle Model:70
Custom built:no
Barrel length and twist: 22" 1-10
Projectile brand, model and weight: 75Vmax
Powder brand and weight: Varget 38.5 grains
LOAD CONSIDERED HOT OR CLOSE TO MAX: no
Primers:CCI
Coal:2.68
Ogive length:NA
Brass:Win
Brass length:2.035
Distance to lands:20 thou

Last edited:
Cartridge: 6mm AI
Rifle brand:Remington
Rifle Model:600
Custom built: Semi Custom - Krieger, McMillan, Timney
Barrel length and twist:Krieger 24” 1:8
Projectile brand, model and weight:Berger VLD Hunting 95gr
Powder brand and weight:H4350 46.7gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: Yes. Stiff bolt lift at 47.5gr
Primers:210M
Coal:
Ogive length:2.330”
Brass:Remington
Brass length:2.20”
Distance to lands:0.010”

Results at 100 : 0.535” Five round average.

Have not ran through chronograph. ***NOTE : this was/is an accuracy load and will not fit in the magazine. Single load only. ***. Did see decent accuracy all through seating depth test. Worst five round group was 0.805” at 0.130” jump. Will be testing 95gr Berger Classic Hunters which will easily seat at magazine length or less.

Cartridge: 6mm AI
Rifle brand:Remington
Rifle Model:600
Custom built: Semi Custom - Krieger, McMillan, Timney
Barrel length and twist:Krieger 24” 1:8
Projectile brand, model and weight:Hornady Vmax 75gr
Powder brand and weight:Varget 44.2gr
LOAD CONSIDERED HOT OR CLOSE TO MAX: Haven’t worked up to pressure yet.
Primers:210M
Coal:
Ogive length:2.307”
Brass:Remington
Brass length:2.20”
Distance to lands:0.020”

Results at 100 : 0.80” Five round average.

Haven’t ran through chronograph yet or fiddled with seating depth. I’m sure it can be further refined. FITS EASILY IN SHORT ACTION MAGAZINE.

Caliber: 243 win
Rifle brand: Savage
Rifle Model: 10
Custom built: sorta, I installed barrel, chassis is MDT
Barrel length and twist:20"
Projectile brand, model and weight: Hornady 75 g Vmax
Powder brand and weight: Hodgon Superformance
LOAD CONSIDERED HOT OR CLOSE TO MAX: nope, light end
Primers: WLR
Coal: 2.64"
Brass: Federal
Brass length: spec

Results at 100: 0.59"
If available:
Velocity (average): 3279 fps
Outside temperature: 8 celcius
Wind and direction: 5 kph from right

Just tried these out, I did 46 g to 48g loads in 0.5 increments. Three shot groups that opened up as charge increased but I have the best group and most consistent speed at the 46 g.

Back
Top Bottom
