NEA Barrel clamp w/bottom rail add on.

[Dmitri]

I decided to bolt a small rail on to the bottom part of the Nea barrel clamp, so i can mount the bipod there.. turned out pretty good... here some pics.. :



[pizdets17]

Man is there anything you DON'T have on that thing lol? Nice work!

I decided to bolt a small rail on to the bottom part of the Nea barrel clamp, so i can mount the bipod there.. turned out pretty good... here some pics.. :



[insurrecto]

nice! did you have to drill it?



[lmar]

I decided to bolt a small rail on to the bottom part of the Nea barrel clamp, so i can mount the bipod there.. turned out pretty good... here some pics.. :

How do you like the Magpul AFG up front?
Make much of a difference?

L



[venom_bullet]

what quad rail is that?



[Dmitri]

How do you like the Magpul AFG up front?
Make much of a difference?

L

i like it a lot.. after having it for a while, it really feels uncomfortable without it

nice! did you have to drill it?

yes drill/tap.. and i also made a grove in the bottom of the rail to prevent turning ..

what quad rail is that?

it is an Infratek Polymer quad railed hand guard that i found on EE...
it is pretty solid, but it has 4 screws you have to take out every time you clean it.. not like the B&T



[mckutzy]

what is the diameter of your barrel for the barrel clamp, also what is the height from the top of the barrel to the top of the rail,



[Charles Martel]

what is the diameter of your barrel for the barrel clamp, also what is the height from the top of the barrel to the top of the rail,

Same as the hand guard. It was made to work with the railed stock adapter and Hand guard.



[Stevo]

Same as the hand guard. It was made to work with the railed stock adapter and Hand guard.

Same as the NEA handguard. Not the same as the one on the pictured rifle.



[mckutzy]

oh, yes i understood that pieces do fit together with each other, i just dont own a vz to actually measure the barrel. just curious if this mount might fit other rifles like a sks.



[Durmius]

Same as the hand guard. It was made to work with the railed stock adapter and Hand guard.

Charles,
A bottom rail alternative for your barrel clamp would be a cool addition.
