Need Help with some .22 pumps.

[greyman441]

I purchased these today as a package deal. All .22's. I don't know very much about them. The top one is a Noble Model 33A. Seems to work great, the middle is a Stevens model 1909. It is missing the clip and the trigger doesn't catch when you pump it. The bottom is a Martel made by National Fire Arms Co. It is missing a bunch of parts. I believe it was made by Marlin but not 100% sure. If it is, does anyone know what model? I would like to fix this as it is a cool gun. If anyone could tell me about these guns it would be appreciated. Also if anyone has a parts list of a schematic they would be willing to share that would help also. The last 2 pics are the Martel internals. What you see is all I got.

Also does anyone know where I could find a clip for the stevens??

Thanks



[mwjones]

Info from 2009 standard catalog of firearms and/or gun digest book of exploded drawings.

Noble Model 33
This is a .22 caliber slide-action rifle fitted with a 24" barrel and tubular magazine and Tenite stock. Produced from the late 1940s to the early 1950s.

Exc. V.G. Good Fair Poor
80 70 60 50 40

Model 33A
Same as above but fitted with a wood stock.
Exc. V.G. Good Fair Poor
75 60 50 40 30

Not in exploded gun drawings

Savage Model 1903
A .22 caliber slide-action rifle with a 24" octagon barrel having
open sights. Blued with a walnut stock. Manufactured between
1903 and 1922. Late model rifles have updated slide handle
and pistol-grip stock in same style as Model 1914.

Model 1909
As above, with a 20" barrel. Manufactured between 1909 and
1915.
Exc. V.G. Good Fair Poor
250 200 150 100 75

Also not in exploded gun drawings

The martel/national firearms company gun is not in either book, although under national firearms company it says see also moore's patent firearms company. the only entries for either are for derringer style pistols.

hope that helps.



[greyman441]

Thanks mwjones. Now im on the hunt for a mag for the savage. I have got some help from some fellow CGN'ers. I pulled it apart to clean it and found a spring that holds the safety is broke. So I am on the hunt for that to.
