Pictures of Sako AV factory detachable magazines.

stickhunter

CGN frequent flyer
Rating - 100%
577   0   0
Location
Victoria, B.C.
I just received a Sako Fiberclass that was rebarrelled in 7mm Remington Magnum and came with a Swarovski 2.5-10x42 Habicht scope with 30mm tube in Optilock rings. The reticle is in the first focal plane, so it changes size with magnification --- first time I've had one so will be interesting to try out.

The barrel is 26" stainless, and although it has no markings, I was told by the original owner that it was likely a McLennan, but who knows. The rebarrelling was done by a gunsmith named George Elliot (I believe that was the name I was told --- anyone heard of him?). I don't know what contour it is, but the muzzle is 0.785" and finished with a nicely recessed crown. Total weight of the rifle, scope, and unloaded magazine is 8lbs 12oz --- not as heavy as I would have thought given the 26" barrel and not-so light stock!

I was most interested in taking a look at the detachable magazine system. It uses the stock bottom metal with the floorplate, magazine spring, and follower removed. The magazines are held by the floorplate release. I received two magazines, each marked "SAKO Mag. Cal. Only \ One Piece Trig. Grd." The magazines are a single column design and hold 3 rounds (I didn't have any 7RM handy, so I used some 338 brass to verify the capacity).

Here are some closeups of the magazine system for those interested. Does anyone have a Sako that uses this system?






Last edited:
Hey stickhunter

That is a detachable mag kit that Stoeger sold in the 80s??? I have owned a few over the years and still have a magnum one. They were all single stack 3 round mag and work fairly well. The one thing I remember is having to modify the catch on the mag so the release worked properly. They were made in standard and magnum kits. They also were made for one and two piece bottom metal rifles. Pre serial #645000 AVs were one piece and post were two piece. Hope this helps.

Is that not the bottom metal and magazine from a TRG-S?

Not the same. The TRG-S looks like this...
