Review,of 1889,1896,96/11,1911.k11,and kadet
1911 Clamp-On Scope Mount.The SP 1911 Clamp-On Scope/Diopter Mount installs quickly on the Rifles. Requires no alteration to the rifle
What you need to scoped the rifle
-3/8 dovetail base .22 ring to fit the rail,why rail is ½ because,cartridge clearance to eject.see pict.
-scope should not have too large of objective,why to clear rear sight see pict.
On the k11 and 1889 32mm should be considered as the maximum diameter possible.
-scope mount made by Swiss product,very stable product hard steel mount,well made and fit perfectly,come with two screws,two sleeves,key for the bolt,and instruction easy do it
For the review I used
Schmidt rubin 1911
Warne scope mounts 7.3/.22 1 inches tube high height
http://www.grouseriver.com/Warne_Maxima_Rimfire_Rings_p/opt-000464.htm
scope is vortex crossfire II 2-7X32
http://www.grouseriver.com/Vortex_Crossfire_2_7x32_p/opt-000489.htm
1-Remove original scews out,take your scope mount with bushing,large in the front small back of the rifle,install bushing with the flangs toward the trigger plate,tighten front screw first.
2-depend on what type of scope you will use.
Loose the base of the scope mount,and slide to the stop (must)
then second base ½ to ¼ from the rear of the rail,tight the base.
3-remove top ring,clean holes with alcohol.
Don’t forget to turn the scope 90 degree,left,so no turret in the way of ejection.
4-put top ring back with screws tighten slowly and keep checking to see the crosshair are straight,alternate full turns of screws until you make contact,like
1st---4TH
3rd---2nd
Then do ¼ turn and check the gap between top and bottom of ring is equal.
Windage is now your up and down
Up and down is your windage,you will get to us it.
On the range about 50m,I put the rifle stable,removed the bolt,see trought the barell,to look at the center of the target,I adjusted up,and down of the scope,and windage,fire few shooted to adjusted,
100 meter I shooted few more round,I got 1 ½ to 2 inches grouping,
I checked the mount for loose scews,nothing moved,and its holding 0,the thing I will had next time will be a cheek pad,my rifle is a Schmidt rubin 1911,still accurate with all those year behind
