Two New Rigs for 2011 - FTR and test rifle

[Mystic Precision]

Stevens LA - Used on my F Open rigs (started life as a 30-06)
223 bolt head - to test my new Shilen F TR barrels and work up loads for the 90gr Bergers
Richards Lamstock
RB 2 trigger
Score Hi Single shot follower
Farrell MOA base
Burris Sig ZEE rings w/ inserts
Sightron SIII LR 10-50X60 FCH
Shilen SS Select Match 223, 7 twist, Bull contour, 28" finished, throated for the 90gr VLD's.

Stevens SA in 223 - new Centerfeed action
Richards Lamstock - thought I would be daring with the colour scheme this time. I like it
RB 2 trigger
SSS single shot mag adaptor. Yes, the det mag bottom metal is utilized.
SSS fancy bolt body. SSS stuff was purchased before the Feds visited.
Farrell MOA base
Burris Sig ZEE rings w/ inserts
Sightron SIII LR 10-50X60 FCH
Shilen SS Select Match 223, 7 twist, Bull contour, 28" finished, throated for the 90gr VLD's.

The barrel in these pics is actually the same barrel. I had the LA set up first for testing while I was finishing the SA. Same brass, same loads, same accuracy.

Jerry



[X-fan]

Nice Jerry!

Those look a lot nicer than the do it yourself synthetic days.
Tactical looking bases and everything!

Did you hollow out the the forend so it rides on the outside edges?



[clatartar]

are those the med or the high sig zees?



[CyaN1de]

An actual production stock......impressive.



[Mystic Precision]

are those the med or the high sig zees?

Xtra high. I like a tall scope when shooting prone,

Jerry



[Mystic Precision]

An actual production stock......impressive.

No time.

Another to be assembled in the coming weeks.

Jerry



[Mystic Precision]

Nice Jerry!

Those look a lot nicer than the do it yourself synthetic days.
Tactical looking bases and everything!

Did you hollow out the the forend so it rides on the outside edges?

NO time to build my own right now.

Farrell bases which I have used on all my rigs for a long while.

Dead flat bottom at this time. I set up my front bag so there isn't a hump in the middle so dishing the bottom of the stock is not necessary.

Jerry



[yodave]

nice looking rigs Jerry, how was the drop in fit of the Richards stocks?

Savage is drying as we speak



[Mystic Precision]

They must have put in new tooling cause the inletting was actually very good.

Jerry



[MXoutdoors]

You got your self some nice rigs their Jerry, I sure do like the bolt handle on the first one



[Mystic Precision]

Yes, you did very nice work.

Jerry



[yodave]

Jerry how is the short action working for the 223 with the 90's seated out to the lands?
I have a line on a old CIL/savage single shot and it got the wheels turning again on my end. Its another weird medium action that matches my 110 for length but it is the single shot action, solid bottom..............can you forecast yet another pile of sawdust on my floor cause I can........



[Mystic Precision]

These are wonderful actions to work on and the last one I saw, I should have bought.

Oh well, just didn't know what I had in my hands.

No issues single feeding in the SA. With the bullet out around 2.6", no way it will work from any mag. Action can easily work with 3" OAL.

Just starting LR load tuning so got alot of lead to send downrange but so far results are very exciting.

Good luck with your new stock. Check on the bolt spacing and action length. The one I had was a 'tween action length.

Jerry



[308BAR]

Beauties, the both of them. Looking forward to the results.



[yodave]

it is a 223 now, bolt spacing now just depicts on where I set up the drill press
but you must have noticed that by now.
