Hi there,
I imagine that most people here own a Beretta 92fs or a Beretta 96 fs or maybe even a old Police issue like the Beretta 96D.
I'd like to hear about your likes and dislikes of your model and what you think or the other models out there new and old alike.
Here are a few specs of most 92/96/98 out there:
The Beretta 92 pistol evolved from earlier Beretta designs, most notably the M1922 and M1951. From the M1922 comes the open slide design, while the alloy frame and locking block barrel (originally from Walther P38) were first used in the M1951. The grip angle and the front sight integrated with the slide were also common to earlier Beretta pistols.
The Beretta 92 first appeared in 1975[1] and was designed by Carlo Beretta, Giuseppe Mazzetti and Vittorio Valle, all experienced firearms designers on the Beretta design team.
92
About 5000 copies of the first design were manufactured from 1975 to 1976.
92S
In order to meet requirements of some law enforcement agencies, Beretta modified the Beretta 92 by adding a slide-mounted combined safety and decocking lever, replacing the frame mounted manual thumb safety. This resulted in the 92S which was adopted by several Italian law enforcement and military units. The later relocation of the magazine release button means these models (92 & 92S) cannot necessarily use later magazines, unless they have notches in both areas.
92SB (92S-1)
The extremely rare 92SB, Initially called the 92S-1, was specifically designed for the USAF (US Air Force) trials (which it won), the model name officially adopted was the 92SB. It included the changes of the 92S, added a firing pin block (thus the addition of the "B" to the name), and relocated the magazine release catch from the bottom of the grip to the lower bottom of the trigger guard.
* 92SB Compact (1981–1991), shortened barrel and slide (13-round magazine capacity). It was replaced by the "92 Compact L".
92F (92SB-F)
Beretta modified the model 92SB slightly to create the 92SB-F (the "F" added to denote entry of the model in U.S. Government federal testing) and, later, the 92G for French Government testing, by making the following changes:
* Design of all the parts to make them 100% interchangeable to simplify maintenance for large government organizations.
* Modified the front of the trigger guard so that one could use finger support for easier aiming.
* Recurved the forward base of the grip to aid aiming.
* Hard chromed the barrel bore to protect it from corrosion and to reduce wear.
* New surface coating on the slide called Bruniton, which allegedly provides better corrosion resistance than the previous plain blued finish.
92FS
The FS has an enlarged hammer pin that fits into a groove on the underside of the slide. The main purpose is to stop the slide from flying off the frame to the rear if it cracks. This was in response to reported defective slides during US Military testing.
Design
The Beretta 92's open slide design ensures smooth feeding and ejection of ammunition and allows easy clearing of obstructions. The hard-chromed barrel bore reduces barrel wear and protects it from corrosion. The locking block barrel lockup provides good accuracy and operability with suppressors due to the in-line travel of the barrel. This is in contrast to the complex travel of Browning designed barrels. The magazine release button is reversible with simple field tools. Reversing the magazine release makes left-handed operation much easier.
Increasingly, it has become popular to reduce handgun weight and cost (and increase corrosion resistance) using polymers, and polymer parts have started showing up in Beretta 92/96 models too. In 2003, the first internal polymer part to be introduced was a recoil spring guide. New polymer parts include safety lever, trigger, mainspring cap, magazine floorplate, and follower. In contrast some parts have been painted black to match the included polymer parts, these include; slide release, disassembly latch, and hammer.
The 92 also spawned several variants of similar internal design. The Beretta 90two is a full-size variant of the 92-series with a redesigned frame, slide, and grip, and has an accessory rail.
Variants
The French-made PAMAS G1 variant.
The Beretta 92 is available in many configurations each with a distinct model name. Combining the various options results in more than 50 different configurations, but the major variants are defined by their operation caliber (92/96/98), operation (F/G/D) and combination of optional items (Inox/Brigadier slide/Compact length):
Calibers
Each model name starts with two digits identifying the caliber:
92
Chambered for the 9x19mm Parabellum.
93
Chambered for the 9x19mm Parabellum as above but is capable of semi-auto, full auto, or three round burst. Weapon was originally equipped with a 13 round magazine and a 20 round magazine.
96
Chambered for the .40 S&W, introduced in 1990.
98
Chambered for 9x21mm IMI. This option was introduced in 1991 for markets where it is illegal to own a weapon chambered for a military cartridge such as 9x19mm - essentially, this is the case of Italy. There were also about 5000 early 98F manufactured in .30 Luger.
Operation
F Models
Also known as the 92SB-F, the model 92 F was developed in 1983 as a further modification of the model 92 SB that featured a slightly reshaped grip, plastic grip panels and a new, more durable finish. The current production version of the 92 F has a double-action first trigger pull, followed by a single-action trigger pull for subsequent rounds. The "F" and "FS" models have a safety lever that also functions as a decocking lever. The 92 FS was submitted for USA XM9 Army Pistol Trials in 1985 and adopted by the US Army as the M9 Pistol. It is manufactured both in Italy and in USA, and has also been adopted by many other military and law enforcement groups. The 92 FS features a chrome-lined barrel, recurved triggerguard for improved two-handed grip, new grip panels and lanyard ring, Bruniton finish, and trigger bar disconnect safety.
G Models
The G models (designed for the French "Gendarmerie Nationale") were adopted by the French Military as PAMAS ; they feature a manual decocking lever only instead of the safety-decocking lever of the 92 FS. When the decocking lever is released, it automatically returns to the ready to fire position. There is no manual safety.
DS Models
The DS models are "double action only" pistols: the hammer always follows the slide forward to come to rest in the double action position (the hammer never stays cocked). The hammer spur has been removed, and is flush with the rear of the slide. The manual safety lever on the slide provides the same function as it does on the 92 FS.
D Models
The D models are also "double action only" pistols. They are identical to the DS models but without the manual safety (the lever has also been eliminated).
Centurion Models
These pistols offer the frame (and same magazine capacity) of the basic 92 FS model and the reduced length of the Compact version. Special G Centurion, DS Centurion and D Centurion models are available in some countries.
Competition Conversion Kit Models
The standard model can be converted with a special conversion kit into a competition target pistol. The kit includes a 7.3 in (190 mm) barrel with counterweight and elevated front sight, a fully-adjustable target rear sight and ergonomic walnut grips.
Target Models
Designed for competition shooting, these models meet all U.I.T.S. standards for large caliber pistols (P.G.C.). They differ from basic 92 FS in the following aspects: 150 mm (5.9 in) barrel, with aluminum counterweight sleeve, fully-adjustable target rear sight, ergonomic walnut grips with "orange peel" anti-slip finish.
Inox Models
The Inox models (from the Italian "inoxidable" meaning non-oxidizing) feature the following parts made in stainless steel: the barrel, the slide (including the extractor, the safety and the right-side manual safety lever), the trigger (and trigger pin), and slide stop lever.
Options
Vertec
(2003 –)
* New vertical grip.
* Short-reach trigger.
* Thinner grip panels.
* Integral accessory rail.
* Removable front sight (can be replaced with Tritium sight).
* Beveled magazine well (to enable easier/faster reloading).
Brigadier
(1993–2006)
60-gram (2.1 oz) heavier slide and 1 millimetre (0.039 in) wider to improve control when firing multiple shots in quick succession. It also includes removable front and rear sights.
92G Elite IA
Elite I
(1999–2001)
Pistols with this option include the heavier Brigadier bruniton slide with front serrations and Elite designation, Inox finish (silver) stainless barrel, thin skeletonized hammer, and bevel of the magazine well. A flat hammer spring cap was standard as well as the decock only (G-Model) feature and dovetailed front sight. It was introduced in 1999 and replaced by the Elite II option in 2001.
Elite IA
(2001–2006)
This option is essentially a black Vertec with a bruniton Brigadier G slide having the Elite 1A designation and a thicker skeleton hammer. The 4.7 in (120 mm) stainless barrel with Inox finish was also changed to the blackened stainless version like black Vertecs.
Elite II
(2001–2006)
This option replaced the Elite I option in 2001 and includes the same features as the original Elite plus removable Novak type sights, extended magazine release catch, checkered front/rear grip strap, thicker (than Elite I) skeletonized hammer, and lighter D-spring. This option is available only with the stainless G-Model slide, also with front serrations. The stainless barrel for the Elite II has a target crown.
Inox
(present)
Stainless barrel and slide (frame anodized to match color). Can have either black or stainless controls.
Compact L
(1992 –)
Shorter barrel, slide, and more compact frame (13-round magazine capacity).
Compact Type M
(1992 –)
Similar to the Compact L, but has a slimmer grip that accepts only a single stacked 8-round magazine.
Centurion
(1992–1997)
Shorter barrel and slide (like "Compact"), but with standard-sized frame that has a slightly shorter dust cover.
CB
(1992–1993)
Single action only. It is designed for sport shooting and includes a front barrel bushing for improved accuracy.
Stock
(1994 –)
Heavier Brigadier slide. It is also designed for sport shooting and includes a front barrel bushing for improved accuracy.
Combat
(1994–2001)
Heavier Brigadier slide, single-action only and also designed for sport shooting, including a front barrel bushing for improved accuracy. It also came with an additional longer barrel that was weighted.
Billennium
(2001 only)
A limited-edition (2000 copies) commemorative (of the year 2000) model manufactured in 2001, featuring the heavier Brigadier slide.
Steel I
(2004–2006)
Stainless steel, single-action-only, collector's model. [Edit: Both single-action-only and single/double-action variants exist. Also used and desirable for competitive shooting because of its steel frame (for added weight and strength), the frame-mounted safety and/or Vertec-style grip-frame that are all found to be desirable features in a competition gun.]
Magazine capacity
To keep in line with the introduction of laws in some locations restricting magazines that hold more than 10 rounds, Beretta now manufactures magazines that hold fewer than the factory standard 15 rounds. These magazines have heavier crimping (deeper indentations in the side) to reduce the available space while still keeping the same external dimensions and ensuring that these magazines can be used on existing firearms.
Italian magazine manufacturer Mec-Gar now produces magazines in blue and nickel finishes with a 18 round capacity, which fit flush in the magazine well on the 92 series. Mec-Gar also produces an extended 20 round blued magazine that protrudes below the frame by 3⁄4 inches (19 mm). These magazines provide users in unrestricted states with an even higher capacity.
93R
Beretta 93R
The Beretta 93R is a significantly redesigned 92 to provide the option of firing in three-round bursts. It also has a longer ported barrel, heavier slide, fitting for a shoulder stock, extra forward grip, and an extended magazine. Unlike other Berettas in the 90 series it is single-action only, does not have a decocker, and very few are around today.
92A1 and 96A1
A new model of Beretta 92 series called 92A1, was introduced in 2010. It is based on the elements of 92FS and 90two. The overall shape and styling of the 92A1 is based on the 92FS with an accessory rail on the underside of the frame, while internal design is based on 90two. The 96A1 is the variant of 92A1 chambered for .40 S&W.
*Special thanks to Wiki for the info.
I'll try and get some picx to put up for the different models
And put up some information on how the USMC modify the 92 to shoot less than 2 inches @ 25yards (yup , no joke)
I'd like to see your Beretta if you have picx or is modified in any way or form.
Thanks for reading
1ronM@n
