Norinco AR(T97) mag review update pg 3

[Craig0ry]

You'd only sell to me once then.

It's a good thing I don't work retail, I probably wouldn't make it very far



[Deckard]

Seems like the magazine is designed in that old tricky manner. We can use your mag, but you can't use ours. Yeah I know their rifle is different but I can't figure out why those magazines would be so out of spec.



[Craig0ry]

I'll post some updated pics later, the issue was even more simple to fix than I initially thought. Once I figured that out I ordered another 10



[Craig0ry]

Well this is my solution to the mag problem, Only one side of the mag needs to be ground down in order for them to function properly in my AR, they work without any modifications in my 180B other than removing the forward rivet leaving the rear rivet intact.

This pic shows the side that needs to be taken down.


Here's a picture of the mag inserted without the modification, the metal pushes upwards on the slide release not allowing it to be depressed.



here's another rough grind job as I have a very fine grinding wheel on order from HH


Here's how a mag should be able to operate when inserted



And for 5$ each I think these are worth the trouble, I hope the other people who bought some of these see this post and it helps them out as well
