Dillon 1050 Mod.

[RePete]

I was reading an FAQ on Brian Enos forum and saw something that caught my eye, so I tried it and surprise, surprise it works.

The 1050 spent primer catcher sucks the BIG one. I had removed it and used a funnel and a piece of clear hose to ferry the primers away. It left a little to be desired but worked.

This mod involves cutting the case head from a .223 case (i used a Remington), placing an appropriate size and length of clear tubing on the cut end, and jamming the case neck into the ejection hole on the press.



[757Fixer]

Would the mod. work if you ran out of clear tubing and used some kind of opaque tubing?



[RePete]

Why not. I had clear, but also, it there is a blockage you will see it.



[Canuck223]

Great idea. On mine, 1/3 of the primers bounced out on to the floor or bench.



[Slavex]

good mod, my older 1050 works good with the metal bin for spent primers.

man I coughed up a lung laughing at 757's post.



[bear.23]

i miss my 1050 I want this thing over and done so I can start shooting again.............


I can't talk about it but I can say we made it past another hurdle and things are back on track......



[stormbringer]

Gee that is exactly what comes standard on my LNL AP...

A nice clean tube to take away the spent primers. Not like the Lee that gathered them so they fell on the floor and you step on them with bare feet!



[762nato]

Another good mod it to cut off a hex key and put it in the pivot pin for the priming system. This is then held in place by a piece of all round on one of the bolts for the swage set up. Keeps the pin from backing out. One of the few problems with a 1050.

Andy



[bear.23]

There is also another mod for the primer system for the tubing and the pins for carrier but I don't remember but what it was.. copper or brass shims ring a bell



[bear.23]

OK I'm in a 1050 mood who wants one... see my ad in the dealers forum..



[RePete]

Another good mod it to cut off a hex key and put it in the pivot pin for the priming system. This is then held in place by a piece of all round on one of the bolts for the swage set up. Keeps the pin from backing out. One of the few problems with a 1050.

Andy

Pics Andy?



[tgt40]

The tube set up works great on a 650 too. Just be sure to look under your station 1 locator to be sure no primers build up under your decapping pin.



[762nato]

Thanks for the primer mod idea Pete, keep my press much cleaner.

Andy



[RePete]

Thanks for the primer mod idea Pete, keep my press much cleaner.

Andy

You're welcome.

Just adapting and passing on info that I gleened.
